- Power supply: AC220V, frequency: 50Hz;
- Input power: 680VA;
- Maximum carrying capacity: 135KG;
- Headrest telescopic range: 120mm;
- Backrest backward range: 115~180 degrees;
- The highest height of cushion from the ground: 780mm;
- The lowest height of cushion from the ground: 400mm.
1. Base
New base (steel paste with strong PU cover) with 28mm thickness.
![Dental Chair Foshan](/Uploads/202108/6120699d302a0.png)
2. Floor box
Built-in floor box, save space.
![Dental Chair Foshan](/Uploads/202108/612069cbdc843.png)
3. Chair Frame
With linkage-movement function and collision avoidance system, make it safe and make you comfortable.
4. PU Cushion
6. Aluminum Backrest
Aluminum backrest makes the chair more stronger
5. Left-hand and Right-hand operation
Turnable tool tray and unit box, suit for left-hand and right-hand dentists operation.
7. Headrest
The headrest can be slide along the track,can be adjusted for the children.
8. Rotary Unit Box 9. Ceramic Cuspidor
Rotary ceramic cuspidor with 180-degrees. Rotary ceramic cuspidor with 180-degrees.
10. Tool Tray
Intelligent key-touch control system with 9 memory positions.
11. Assistant Tray
Intelligent key-touch assistant control system.
12. LED Shadowless Lamp
LED operation lamp,the handle can be removed for disinfection,
360-degree rotation.
![Dental Chair Foshan](/Uploads/202201/105.png)
13. Suction Holder
New type strong and weak suction holder.
14. Motors
24V DC Timotion brand from Taiwan.
15. Tubes
Air and water tubes from USA.
![Dental Chair Foshan](/Uploads/202108/61206cf602c8b.png)
16. Foot Pedal
Mutil-function foot pedal.
![Dental Chair Foshan](/Uploads/202108/6120a9fbaf718.png)
17. Dentist Stool
![Dental Chair Foshan](/Uploads/202201/112.png)
![Dental Chair Foshan](/Uploads/202201/113.png)
18. Different Cushion Colors for Chair
![Dental Chair Foshan](./Uploads/202201/5-1.jpg)
![Dental Chair Foshan](/Uploads/202201/125.jpg)
Standard specification:
1. hole high-speed handpiece tubing with connector 2 sets;
2. 4 hole low-speed handpiece tubing with connector 1 set;
3. 3-way syringe (cold and hot) 2 piece;
4. Adjustable headrest 1 set;
5. Double armrest 1 set;
6. Down-mounted tool tray with touch control 1 set;
7. 6-posistion for handpieces ,syringe, scaler and micro motor 1set;
8. Suction and saliva ejector 1 set each;
9. LED operation lamp with sensor CX-152 1 set;
10. American style lamp arm 1set;
11. Build-in model Lcd X-film viewer 1 set;
12. 24V DC motors 1 set;
13. Assistant tray with touch control 1 set;
14. Water purified system 1 set;
15. Water heating system 1 set;
16. Water bottle 600ml 1 pcs;
17. Auto water supply and flush cuspidor system 1 set each;
18. Ceramic cuspidor with 180-degrees rotation 1 set;
19. Multi-function foot pedal CX-106 1 set;
20. Big size dentist stool with double adjust CX-147 1 piece;
21. PU cushion 1 set;
22. Aluminium backrest 1set;
23. Imported Solenoid valve CX-097 2 pcs;
24. ABS plastic covers 1 set;
25. Imported air and water tubes 1set;
26. Imported strong and weak suction tube 1set;
27. All kinds of copper valves 1set;
28. Chair with 9 memory positions 1set;
29. Chair without safety system;
30. Linked movement chair frame;
31. New base(steel paste with strong PU cover);
32. Packing size: 170*115*125CM;
33. Gross Weight: 320KG
