- Power supply: AC230V, frequency: 50Hz;
- Input power: 680VA;
- Maximum carrying capacity: 135KG;
- Headrest telescopic range: 120mm;
- Backrest backward range: 115~180 degrees;
- The highest height of cushion from the ground: 780mm;
- The lowest height of cushion from the ground: 400mm.
1. Base
New base (steel paste with strong PU cover) with 28mm thickness.
2. Floor box
Built-in floor box, save space.
3. Cushion
With linkage-movement function,make it safe and ke you comfortable.
4. PU Cushion
5. Bending plate
PU bending plate with 26mm thickness.
6. Headrest
The headrest can be slide along the track,can be adjusted for the children.
7. Tool Tray
Intelligent key-touch control system with 9 memory positions.
8. Assistant Tray
Intelligent key-touch assistant control system with a table for assistant.
9. Silicone Pad For Tool Tray
Silicone pad which is autoclavable, its maximum bearing temperature is 135℃.
10. Silicone Pad for Assistant Tray
Silicone pad which is autoclavable, its maximum bearing temperature is 135℃.
11. Rotary Handpiece Holder
360-degrees rotary handpiece holder
12. Suction Holder
New type strong and weak suction holder
13. New Type Unit Box
14. Ceramic Cuspdor
15. Implant LED Lamp
The sensor implant LED lamp can be switched between white light and yellow light,the color mperature is adjustable.
16. Motors
24V DC Timotion motors from Taiwan,China.
17. Tubes
Air and water tubes from USA.
18. Foot Pedal
Mutil-function foot pedal
19. Dentist Stool
Different Cushion Colors for Chair
21. The feedbacks from our customers
Standard Specification:
2 or 4 hole high-speed handpiece tubing with connector 2 sets;
2 or 4 hole low-speed handpiece tubing with connector 1 set;
3-way syringe (cold and hot) 2 piece;
Adjustable headrest 1 set;
New design double armrest 1 set;
New design down tray with rotary holder with touch control 1 set;
With autoclavable silicone pad,maximum bearing temperature is 135-degrees 1pcs;
5-posistion for handpiece,syringe and scaler 1set;
Suction and saliva ejector 1 set each;
LED operation lamp with sensor(white and yellow light) CX-206 1 set;
American style lamp arm 1set;
Build-in model Lcd X-film viewer 1 set;
24V DC motors 1 set;
Assistant tray with touch control 1 set;
Water purified system 1 set;
Water heating system 1 set;
Water bottle 600ml 1 pcs;
Auto water supply and flush cuspidor system 1 set each;
Ceramic cuspidor with 180-degrees rotation 1 set;
Multi-function foot pedal CX-106 1 set;
Big size dentist stool with double adjust CX-147 1 piece;
PU cushion 1 set;
Solenoid valve 2 pcs;
ABS plastic covers 1 set;
PVC air and water tubes 1set;
All kinds of copper valves 1set;
Chair without safety system;
Linked movement chair frame;
New base(steel paste with strong PU cover);
Packing size: 142*100*125CM;
Gross Weight: 260KG.
